10t steerable battery transfer trolley on cement ground with PU wheels for aluminium coil factory

Name: 10t steerable battery transfer trolley on cement ground with PU wheels for aluminium coil factory
Brand: Topleader
Price: 5000 USD

Wholesale 10t steerable battery transfer trolley on cement ground with PU wheels for aluminium coil factory from china suppliers

Brand Name : Topleader

Model Number : BWP

Certification : CE,ISO9000

Place of Origin : China

MOQ : 1 set

Price : $5000-$15000

Payment Terms : L/C, T/T, Western Union

Supply Ability : 600 sets/year

Delivery Time : 50 days after receive your prepayment

Packaging Details : The whole cart will be packed by the tarp, the parts will be packed by polywood case.

Product name : 10t steerable battery transfer trolley on cement ground with PU wheels for aluminium coil factory

Power supply : Storage battery

Material : Q235 Steel plate and PU wheel

Load capacity : 1-100T

Running speed : 0-20m/min

Application : Factory ,warehouse and working line

Warranty : 1 year

Color : customized

OEM : Accepted

Contact Now

10t steerable battery transfer trolley on cement ground with PU wheels for aluminium coil factory

Working Principle --- Steerable Battery Transfer Trolley

10t steerable battery transfer trolley is powered by storage battery. The battery is installed in the steerable battery transfer trolley and we also equip intelligent charger for it. The steerable battery transfer trolley is controlled to go forward, backward, turn left, turn right, adjust speed through PLC and speed controller.

10t steerable battery transfer trolley on cement ground with PU wheels for aluminium coil factory

Description --- Steerable Battery Transfer Trolley

The steerable battery transfer trolley is composed of motor, reducer, electric appliance and wheels. Due to more parts, compared with other carts, it has large size. But it travels flexibly.

The driving wheel and load wheel of battery transfer trolley is high strength PU wheel. It is wear-resistance, and has low maintain cost.

The functions of the transfer trolley including 360 degree turning, go forward and backward,turn left and right, adjust speed button, indicator light, electric indicator light and other control buttons.

Application --- Steerable Battery Transfer Trolley

This kind of ssteerable battery transfer trolley is commonly applied in factory or warehouse to transfer heavy materials, such as steel workpiecs, machine parts, etc.

Technical Parameters --- Steerable Battery Transfer Trolley

Model	BWP-10T
Rated Load(t)	10t
Impacted rated load(t)	15
structure of frame	steel plates welded beam structure
Thickness of the steel plate	10
Cart weight(t)	5.3
Wheel load(t)	4.6
Ground requirement	cement ground
Table size(mm)	3600x2000
Height of the whole cart(mm)	530
Space from the ground(mm)	50
Wheels distance	1500
Axles distance	3100
Turning radius(mm)	3100
Turning type	turning while driving without stop
Control method for turning	control button
Turning structure	mechanical
Wheel diameter	Ф300/4
Wheel quality	polyurethane wheels
Running speed(m/min)	0-15
Brake principle	electric magnetic force
Operation method	with wire or no wire
Charger motor's installation	installed on cart
Function of charger motor	automatic charging
Warning equipment	sound and light

Advantages --- Steerable Battery Transfer Trolley

The motor adopts DC traction motor, the protection grade: IP44. Compact structure, large overload capacity, long service life. Excellent load performance, good low-speed performance, big starting torque, small starting current. It is suitable for frequent start and saves electricity. The motor runs with high efficiency in the range of all speeds. The motor adopts imported high-speed bearing retaining oil, and it is of free maintenance, high reliability and long service life.

10t steerable battery transfer trolley on cement ground with PU wheels for aluminium coil factory

Manufacturing Process --- Steerable Battery Transfer Trolley

10t steerable battery transfer trolley on cement ground with PU wheels for aluminium coil factory

Package & Delivery --- Steerable Battery Transfer Trolley

Our Sale Performance --- Steerable Battery Transfer Trolley

No.	Exported countries	Product name	Product model	Quantity	Unit
1	Thailand	Rail transfer cart	KPDZ-16T	2	sets
2	Germany	Battery power transfer car	KPX-10T	2	sets
3	Syria	Battery power transfer car	KPX-120T	1	set
4	Syria	Battery power transfer car	KPX-30T	1	set
5	Turkey	Battery power transfer car	KPX-40T	3	sets
6	South Africa	Battery power transfer car	KPX-6T	2	sets
7	Nepal	Battery power transfer car	KPX-6T	2	sets
8	Singapore	Cable power transfer car	KPJ-15T	1	set
9	Singapore	Cable power transfer car	KPJ-10T	1	set
10	Singapore	Towed transfer car	KP-15T	1	set
11	Mongolia	Cable power transfer car	KPJ-30T	2	sets
12	Saudia Arabia	Cable power transfer car	KPX-60T	2	sets
13	Austrilia	Battery power transfer car	KPX-60T	1	set
14	Singapore	Hoist trolley	HB-4T	1	set
15	Singapore	Hoist trolley	HB-15T	2	sets
16	India	Battery power transfer car	KPX-20T	1	set
17	Singapore	Electric turntable		2	sets
18	Mexico	cable power transfer car	KPJ-60T	1	set
19	Turkey	cable power transfer car	KPJ-10T	1	set
20	Saudia Arabia	Busbar powered transfer car	KPC-10T	1	set
In order to protect clients' information, client's company names keep secret
